HPE DL380 Gen10 Xeon-G 5218 Kit-P02498-B21

Description

HPE DL380 Gen10 Xeon-G 5218 Kit Overview

The HPE DL380 Gen10 Xeon-G 5218 Kit is a highly versatile, enterprise-grade server designed for demanding workloads. It is a part of HPE’s ProLiant DL380 Gen10 series, which is known for providing exceptional performance, scalability, and reliability. The Intel® Xeon® Gold 5218 processor in this server delivers high performance with its 16 cores and 32 threads, making it a powerful solution for a wide range of business-critical applications. Whether you’re running virtualized environments, hosting databases, or managing large-scale applications, the HPE DL380 Gen10 with the Xeon-G 5218 is built to handle it with efficiency and ease.

Below is an in-depth look at the features, specifications, and use cases for the HPE DL380 Gen10 Xeon-G 5218 Kit.

Key Features and Benefits

1. Intel® Xeon® Gold 5218 Processor

• 16 cores, 32 threads for high multi-tasking capabilities.
• Base frequency of 2.3 GHz, offering fast processing power.
• The Intel® Turbo Boost Technology enables enhanced performance when required.
• With a 125W TDP, the Xeon Gold 5218 is designed to balance power efficiency with high-performance needs, making it ideal for resource-intensive workloads like virtualization and large-scale databases.

2. Memory Capacity and Scalability

• The HPE DL380 Gen10 Xeon comes with 32GB of RDIMM memory, running at 2933 MT/s. This provides excellent support for both basic and more demanding tasks.
• The HPE ProLiant DL380 Gen10 supports up to 3TB of memory in a range of configurations, allowing for easy upgrades as your business grows.
• With 24 DIMM slots, the server supports RDIMM and LRDIMM types, offering flexibility to configure the right balance of memory for current and future workloads.

3. Storage Flexibility

• The HPE DL380 Gen10 Xeon features the HPE Smart Array P408i-a controller with 2GB cache and Smart Storage Battery, ensuring quick, reliable storage performance and redundancy.
• While the kit does not include HDDs, the server is compatible with a wide variety of drives, including SAS, SATA, and NVMe options. It supports up to 19 2.5-inch drives or 12 3.5-inch drives, offering a range of choices based on your business needs.
• The RAID capabilities support multiple configurations (RAID 0, 1, 5, 10, 50, 60) for data redundancy and integrity.

4. Networking and Connectivity

• Equipped with 4x1Gb Ethernet ports, the HPE DL380 Gen10 Xeon offers essential network connectivity out of the box.
• Optional 10GbE or 25GbE network adapters can be added to support high-performance networking, enabling faster data transfer speeds between the server and other network devices.

5. Power Efficiency and Redundancy

• The HPE DL380 Gen10 Xeon is powered by a single 800W HPE FlexSlot power supply, designed for efficient energy usage and high power density. This reduces the overall operational cost while ensuring that the server delivers optimal performance.
• The FlexSlot power supply is hot-swappable, which means it can be replaced without shutting down the server, reducing downtime in mission-critical environments.
• Redundant power supply options are also available for those who need continuous availability and failover protection.

6. Security and Management

• HPE iLO (Integrated Lights-Out) provides advanced remote management features, enabling IT administrators to monitor, manage, and troubleshoot the server remotely, reducing the need for physical intervention.
• HPE Silicon Root of Trust ensures hardware security, protecting the server from unauthorized firmware attacks and ensuring the integrity of your IT infrastructure.
• Secure Boot and TPM (Trusted Platform Module) support for enhanced security against external threats.

7. Chassis and Form Factor

• The HPE DL380 Gen10 Xeon features a 2U rack-mounted form factor, ideal for organizations with limited space but needing high computational power.
• Tool-less installation makes the server easy to install and configure in data center racks.

8. Warranty and Support

• The 3-year warranty offers comprehensive coverage, including 3-year parts, 3-year labor, and 3-year onsite support with next-business-day response. This ensures that any potential issues are resolved swiftly to minimize downtime and business disruption.

Specifications

• Processor:

  • Intel® Xeon® Gold 5218
  • 16 cores, 32 threads
  • Base frequency: 2.3 GHz
  • Thermal Design Power (TDP): 125W

• Memory:

  • 32GB (1x 32GB) RDIMM
  • 2933 MT/s memory speed
  • Expandable up to 3TB
  • 24 DIMM slots
  • Supports RDIMM and LRDIMM configurations

• Storage:

  • HPE Smart Array P408i-a storage controller
  • 2GB cache and Smart Storage Battery
  • No HDD included, but supports SAS, SATA, and NVMe drives
  • Up to 19 2.5-inch drives or 12 3.5-inch drives

• Networking:

  • Embedded 4x1Gb Ethernet
  • Optional 10GbE or 25GbE network adapters available

• Power Supply:

  • 800W HPE FlexSlot power supply
  • Hot-swappable and energy-efficient
  • Redundant power supply options available

• Chassis:

  • 2U rack-mounted
  • Tool-less installation

• Management:

  • HPE iLO for remote management
  • HPE Silicon Root of Trust for hardware security
  • Secure Boot and TPM support

• Warranty:

  • 3-year parts
  • 3-year labor
  • 3-year onsite support (next business day)

• Dimensions:

  • Height: 87.3 mm (3.44 in)
  • Width: 446.0 mm (17.57 in)
  • Depth: 730.0 mm (28.74 in)
  • Weight: Varies depending on configuration

Ideal Use Cases

The HPE DL380 Gen10 Xeon-G 5218 Kit is designed for a variety of enterprise applications where high performance, scalability, and reliability are essential. Some of the ideal use cases for this server include:

1. Virtualization:

   • The 16-core Xeon processor makes this server ideal for hosting multiple virtual machines (VMs) in environments such as VMware vSphere, Microsoft Hyper-V, or KVM.

2. Database Hosting:

   • Perfect for running enterprise databases such as Microsoft SQL Server, Oracle, or MySQL, the server provides the necessary performance and memory capacity to handle complex queries and large datasets.

3. Enterprise Applications:

   • Can efficiently host applications like Enterprise Resource Planning (ERP), Customer Relationship Management (CRM), and Business Intelligence (BI) software for medium to large businesses.

4. File and Web Hosting:

   • Can be configured as a web server or file server for small to medium-sized businesses, providing secure and reliable access to resources.

5. High-Performance Computing (HPC):

   • With its powerful CPU and scalable memory, the HPE DL380 Gen10 Xeon-G 5218 Kit is suitable for applications in scientific research, engineering, or financial modeling that require significant computational resources.

6. Data Analytics:

   • The HPE DL380 Gen10 Xeon high processing power and memory capacity make it ideal for running big data and data analytics workloads that involve processing large volumes of data.

Conclusion

The HPE DL380 Gen10 Xeon-G 5218 Kit is a robust and versatile server that provides excellent performance, security, and scalability for a wide variety of business applications. Its 16-core Intel® Xeon® Gold 5218 processor, coupled with 32GB of RDIMM memory, offers the power and flexibility required for demanding workloads. With the added benefits of HPE iLO remote management, flexible storage options, and redundant power supplies, the HPE DL380 Gen10 is an ideal choice for businesses looking for reliability and performance in a 2U rack server.

For more details, visit Hewlett Packard Enterprise or explore Radox Kenya for local support and availability.
